AT528L

AT528L

Handheld Battery Meter

                          • Gorgeous dual-colure cast shell
                          • Battery and external power supply
                          • Battery capacity: continuously used for over 8 hours
                          • Double display: ΔABS/Δ%/Sorting Result
                          • Comparator Function: GD/NG VFD Show or HANDLER out
                          • Auto Zero-Adjust for each range
                          • Mini-USB interface,SCPI compatible command sets

 General Characteristics
 Parameter  AC resistance, DC voltage
 Accuracy  Resistance: 0.5%±5dgt   Voltage: 0.5%±5dgt
 Measurement Range  Resistance: 0.1mΩ~200.0Ω   Voltage: 1 mV - 50V
 Speed  2 times/second
 Display Max  Resistance: 3200 Voltage: 5000
 Dimension  210.76mm*130.23mm*37.88mm
 Weight  650g
